Name: Atlas Light Commercial Grade Baseplate 9,000 lbs. Capacity
SKU: 33
Availability: InStock

Commercial Grade Extra Tall 2-Post Lift

Atlas® OHX10000X
10,000 lb Capacity Lift

The Atlas® OHX10000X is a commercial-grade overhead two-post lift built for repair facilities and serious home garages that need true 10,000 lb lifting strength, extra-tall working height, extra-wide drive-thru clearance, and dependable daily performance.

10,000

lb Capacity

True commercial-grade lifting power for vehicles from compact cars to one-ton dually trucks.

152″

Overall Height

Extra-tall overhead design for more comfortable under-vehicle access.

106.8″

Drive-Thru Clearance

Extra-wide clearance for larger vehicles, vans, and ladder trucks.

5/2

Warranty

5-year structural and 2-year hydraulic warranty, parts only.

Extra tall. Extra wide. Built stronger.

More Room to Work on Larger Vehicles.

Engineered with extra lifting height and extra width between the columns, the OHX10000X gives operators more room when driving through the bay and more comfortable working space when servicing vans, trucks, ladder vehicles, and longer wheelbase vehicles.

🏗

Single-Piece Formed Columns
12′ 7″ formed columns with extra-long carriages for strength and support.

↕

Extra Lifting Height
Longer cylinders allow the vehicle to lift higher than many standard lifts.

🔒

Single-Point Lock Release
Convenient lock release system for efficient shop operation.

Premium Features

Commercial Power With Premium Details

🛞

Symmetric Arms

Balanced arm design supports reliable positioning across a wide range of vehicles.

🛡

Automatic Arm Restraints

Helps secure the arms in position during vehicle lifting and service.

⚙

Dual Direct-Drive Cylinders

Engineered for dependable lifting performance in commercial repair environments.

🧰

12-Piece Truck Adapter Set

Includes 2″, 3″, and 6″ adapter heights for added lifting flexibility.

🚗

Rubber Carriage Covers

Rubber covers help protect vehicle doors and reduce contact damage around the columns.

🚦

Padded Shut-Off Bar

Padded overhead shut-off bar adds a layer of protection during lifting operation.

Technical Specifications

Atlas® OHX10000X Product Specs

Category	Specification	Value
Capacity	Lifting Capacity	10,000 lb
Design	Lift Style	Commercial-grade overhead 2-post lift
Dimensions	Overall Height	152″ / 12′ 8″
Dimensions	Overall Floor Width	144 3/8″ / 12′ 3/8″
Dimensions	Outside Column to Column	136″ / 11′ 4″
Lift Height	Maximum Lift Height Without Adapters	74 3/4″
Lift Height	Maximum Lift Height With Adapters	85 3/4″
Clearance	Drive-Thru Clearance	106 7/8″ / 8′ 10 7/8″
Structure	Column Size	9 1/8″ x 11″
Structure	Column Steel Thickness	5 mm
Power	Electrical Requirement	220V single phase, 30A breaker recommended
Installation	Concrete Requirement	Minimum 4″ concrete, 3000 PSI rating
Shipping	Shipping Weight	1,665 lb

Installation Notes

Important Fitment Details

Minimum Ceiling Height

Single-piece columns require at least a 13 ft ceiling to stand and install properly.

Extra Drive-Thru Space

Extra width provides additional clearance when driving through to another bay or lifting larger vehicles.

Adapter Set Included

Includes a free 12-piece truck adapter set with 2″, 3″, and 6″ adapter heights.

Concrete Requirement

Requires a minimum of 4″ concrete with a 3000 PSI rating.

✓ 10,000 lb Capacity
✓ Commercial Grade
✓ Extra Tall & Extra Wide
✓ Truck Adapters Included
✓ Mounting Hardware Included

Atlas Light Commercial Grade Baseplate 9,000 lbs. Capacity
